UTD-1025CL Dijital Depolama Osiloskopu
(UNIT-UTD-1025CL)
İndirim Oranı
:
%58 İndirim
Sepetteki Son Fiyat
Fiyat
:
₺47.379,00(KDV Dahil)
İndirimli
:
₺19.899,18(KDV Dahil)
Sepet Fiyatı
:
Tahmini Teslim Süresi
:
Ürün stoklarımızda kalmamıştır.
| Specifications |
| Model |
UTD1025CL |
| Bandwidth |
25MHz |
| Channels |
1 |
| Sampling rate |
250MS/s |
| Rise time |
≤14ns |
| Memory depth |
12kpts |
| Vertical scale (V/div) |
5mV/div~20V/div |
| Time base scale (s/div) |
10ns/div~50s/div |
| Storage methods |
Setup, waveform, bitmap |
| Trigger types |
Edge, pulse width, video, slope |
| Interface |
Mini USB |
| Multimeter Specifications |
Range |
Accuracy |
| DC voltage (V) |
400mV/ 4V/ 40V/ 400V |
±(1%+5) |
| AC voltage (V) |
400mV/ 4V/ 40V/ 400V |
±(1.2%+5) |
| DC current (A) |
400μA/ 4000μA |
±(1.2%+5) |
| 40mA/ 4000mA |
±(1%+5) |
| 4A |
±(1.5%+5) |
| AC current (A) |
400μA/ 4000μA |
±(2%+5) |
| 40mA/ 4000mA |
±(1.5%+5) |
| 4A |
±(2.5%+5) |
| Resistance (Ω) |
400Ω/4kΩ/40kΩ/400kΩ/4MΩ |
±(1.2%+5) |
| 40MΩ |
±(1.5%+5) |
| Capacitance (F) |
51.2nF/512nF/5.12μF/51.2μF/100μF |
±(3%+5) |
| Display count |
4000 |
| General Characteristics |
| Power |
Li-ion battery: 7.4V 3600mAh; DC adapter: 100V~240V, 50/60Hz input, 9V/4A output |
| Display |
3.5 inches 64k TFT LCD, 320 x 240 |
| Product color |
Red and grey |
| Product net weight |
0.9kg |
| Product size |
199mm x 118 mm x 49mm |
| Standard accessories |
Probe x 1 (1x, 10x switchable), power cord, adaptor, USB interface cable, current-to-voltage convertor, PC software CD, test leads |
| Standard individual packing |
Carton box, carrying bag |
